CS500 XD Series
Wireless Headset System
Triple the number of wireless headsets in the same space without compromise
Shop
CS500 XD Series
Models
CS545 XD, Convertible
CS540 XD
CS520 XD, Over-the-head Binaural
CS520 XD, Over-the-head Binaural
More headsets. More wireless freedom.
The Plantronics CS500 XD Wireless Headset Series was designed to address wireless density issues*, so that more wireless headsets can be used in the same space while maintaining clear conversations. Using 900 MHz technology, the CS500 XD Series provides up to 350 feet of range, and includes a convertible headset with a hot swappable battery (CS545-XD) for unlimited talk time.
Superior call management
With one-touch call answer/end, vol+/-, and mute, manage calls from up to 350 feet from the charging base. The CS500 XD system also enables you to conference in up to three additional headsets for easier collaboration and guest headsets can subscribe to a base by simply docking the headset. Use with Electronic Hook Switch Cable or Handset Lifter to remotely answer/end calls.
Outstanding audio quality
Your choice of narrow or wideband professional grade audio quality — choose narrowband to extend talk time or wideband mode to enable clearer conversations. An extended boom and noise-canceling microphone filter out background noise, so listeners can hear conversations clearly and enhanced Digital Signal Processing (DSP) provides more natural sound, delivering clear audio the way it’s intended to be heard.
Wearing style choice
The CS500 XD Series offers you a choice of three comfort-tested wearing options to match your personal style:
- Convertible: over-the-ear, over-the-head, behind-the-head*
- Over-the-head monaural: covers one ear for comfort and awareness of environment
- Over-the-head binaural: covers both ears for comfort, focus and blocking out background noise
Power in the base
A sleek charging base is included with the CS500 XD Series. An adaptive power system optimizes for range and talk time by automatically downshifting to low power when the headset is close to the base to save battery life.
Features
Specifications
| Connects to | Desk phone |
| Ideal for | Enterprise office environments with a large concentration of desk-centric workers looking for a simple-to-set-up, simple-to-use wireless offering for managing desk phone calls |
| Talk time | CS545-XD: Unlimited** CS540-XD: Up to 6 hrs CS510-XD/CS520-XD: Up to 8.5 hrs |
| Headset weight | CS540-XD/CS545-XD Convertible: 21 g CS510-XD Over-the-head (monaural): 72 g CS520-XD Over-the-head (binaural): 94 g |
| Wireless frequency | 900 MHz, range up to 350 ft |
| Audio performance | Narrowband or wideband: up to 6,800 Hz |
| Hearing protection | CS510-XD, CS520-XD, CS540-XD, CS545-XD: SoundGuard: protects against sound levels above 118 dBA |
| Models | CS545-XD: Convertible + unlimited talk time** CS540-XD: Convertible CS520-XD: Over-the-head, binaural CS510-XD: Over-the-head, monaural |
| * | Neckband sold separately |
| ** | Includes a spare battery and charging cable for unlimited talk time |
