Camera

Image Sensor

1/2.7 inch CMOS

Effective Pixels

1920 (H)×1080 (V), 2MP

Electronic Shutter Speed

PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s

Minimum Illumination

0.02Lux/F1.85, 30IRE, 0Lux IR on

IR Distance

30m (98.42ft)

IR On/Off Control

Auto; manual

IR LEDs Number

1

Pan/Tilt/Rotation Range

Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°

Lens

Lens Type

Fixed-focal

Mount Type

M12

Focal Length

2.8mm; 3.6mm

Max. Aperture

F1.85/F2.0

Angle of View

2.8mm: 118°×103°×59° (diagonal×horizontal×vertical)
3.6mm: 103.8°×87.5°×47° (diagonal×horizontal×vertical)

Iris Type

Fixed iris

Close Focus Distance

0.5m (1.64ft)/0.9m (2.95ft)

DORI Distance

2.8mm: D: 37m (121ft), O: 15m (49ft), R: 8m (26ft), I: 4m (13ft)
3.6mm: D:53m (174ft), O: 21m (69ft), R: 11m (36ft), I: 5m (16ft)

Video

Video Frame Rate

CVI:
PAL: 1080P@25fp; 720P@25fps; 720@50fps
NTSC: 1080P@30fp; 720P@30fps; 720@60fps
AHD: PAL: 1080P@25fp; 720P@25fps
NTSC: 1080P@30fp; 720P@30fps
TVI: PAL: 1080P@25fp; 720P@25fps; 720@50fps
NTSC: 1080P@30fp; 720P@30fps; 720@60fps

CVBS: PAL: 960H
NTSC: 960H

Resolution

1080P (1920×1080); 720P (1280×720); 960H (960× 576/960×480)

Day/Night

Auto switch by ICR

BLC

BLC/HLC/DWDR

WDR

DWDR

White Balance

Auto; manual

Gain Control

Auto; manual

Noise Reduction

2D NR

Smart IR

Yes

Mirror

Off/On

Privacy Masking

Off/On (8 Area, Rectangle)
