Camera

Image Sensor

1/2.7 inch CMOS

Effective Pixels

2560 (H) × 1440 (V), 4MP

Electronic Shutter Speed

PAL:1/25s–1/100000s
NTSC:1/30s–1/100000s

Minimum Illumination

0.03Lux/F2.0, 30IRE, 0Lux IR on

IR Distance

Distance up to 80 m (262.46 ft)

IR On/Off Control

Auto; manual

IR LEDs Number

2

Pan/Tilt/Rotation Range

Pan: 0°–360°
Tilt: 0°–180°
Rotation: 0°–360°

Lens

Lens Type

Fixed-focal

Mount Type

M12

Focal Length

3.6 mm; 6 mm; 8 mm

Max. Aperture

F2.0

Angle of View

3.6 mm: 89.5° × 76.4° × 41.6°

(diagonal × horizontal × vertical)
6 mm: 55.5° × 48.6° × 27.9°

(diagonal × horizontal × vertical)
8 mm: 41.9° × 36.3° × 20.3°

(diagonal × horizontal × vertical)

Iris Type

Fixed iris

Min Photographic Distance

1.4 m/2.5 m/4.5 m (4.59 ft/8.20 ft/14.76 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

3.6 mm

80.0 m (262.46 ft)

32.0 m (68.89 ft)

16.0 m (52.49 ft)

8.0 m

(26.24 ft)

6 mm

120.0 m (393.70 ft)

48.0 m (104.98 ft)

24.0 m (78.74 ft)

12.0 m (39.37 ft)

8 mm

160.0 m (590.55 ft)

64.0 m (209.97 ft)

32.0 m (68.89 ft)

16.0 m

(52.49 ft)

Video

Video Frame Rate

CVI: 4M@25fps/30fps; 1080P@25fps/30fps;
AHD: 4M@25fps/30fps;
TVI: 4M@25fps/30fps;
CVBS: 960H

Resolution

4MP (2560 × 1440); 1080P (1920 × 1080); 960H (960 × 576/960 × 480)

Day/Night

Auto switch by ICR

BLC

BLC/HLC/DWDR

WDR

DWDR

White Balance

Auto; manual

Gain Control

Auto; manual

Noise Reduction

2D NR

Smart IR

Yes

Electronic Defog

Yes

Mirror

Off/On

Privacy Masking

Off/On (8 area, rectangle)

Certifications

Certifications

CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Port

Video Port

Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Power

Power Supply

12V±30% DC

Power Consumption

Max 5.1W (12V DC, IR on)

Environment

Operating Temperature

-40°C to +60°C (-40°F to +140°F);

<95% (non-condensation)

Storage Temperature

-40°C to +60°C (-40°F to +140°F);

<95% (non-condensation)

Protection Grade

IP67

Structure

Casing

Metal front face + plastic main body + metal bracket

Dimensions

240.7 mm × 90.7 mm × 90.4 mm (9.48″ × 3.57″ × 3.56″)

Net Weight

410 g (0.90 lb)

Gross Weight

616 g (1.36 lb)
