Camera

Image Sensor

Two 1/2.8” 2Megapixel progressive scan CMOS

Effective Pixels

1920(H)x1080(V)

RAM/ROM

512MB/256MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3(4)~1/100000s

Minimum Illumination

0.009Lux/F2.0( Color,1/3s,30IRE)

0.07Lux/2.0( Color,1/30s,30IRE)

0Lux/F2.0(IR on)

S/N Ratio

More than 50dB

IR Distance

Distance up to 20m (66ft)

IR On/Off Control

Auto/ Manual

IR LEDs

10 x 2

Lens

Lens Type

Fixed

Mount Type

Board-in

Focal Length

2.8mm (3.6mm optional)

Max. Aperture

F2.0 (F2.1)

Angle of View

H: 110° (86°), V:60° (46°)

Optical Zoom

N/A

Focus Control

Fixed

Close Focus Distance

N/A

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

41m(134ft)

16m(52ft)

8m(26ft)

4m(13ft)

3.6 mm

55m(180ft)

22m(72ft)

11m(36ft)

6m(20ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Pan:±90˚; Tilt:0˚~65˚; Rotation:0˚~360˚

Intelligence

Event Trigger

Motion detection, Video tampering, Scene changing,

Network disconnection, Ip address conflict, Illegal

access, Storage anomaly

IVS

Tripwire, Intrusion, Object Abandoned/Missing

Advanced Intelligent Functions

Face Detection

Video

Compression

H.265/H.264H/MJPEG(Sub Stream)

Smart Codec

N/A

Streaming Capability

2 Streams

Resolution

1080P(1920×1080)/1.3M(1280×960)/

720P(1280×720)/D1(704×576/704×480)/

VGA(640×480)/CIF(352×288/352×240)

Frame Rate

Main Stream:

CH1: 1080P (1~25/30fps)

CH2: 1080P (1~25/30fps)

Sub Stream:

CH1: D1(1~25/30fps)

CH2: D1(1~25/30fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 32~10240Kbps

H.265: 12~7168Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

BLC / HLC / WDR（120dB）

White Balance

Auto/Natural/Street Lamp/Outdoor/Manual

Gain Control

Auto/Manual
