Camera |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor |
1/1.8” 8Megapixel progressive CMOS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Effective Pixels |
3840 (H) × 2160 (V) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ROM |
4 GB |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM |
2 GB |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System |
Progressive |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100000 s |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Min. Illumination |
0.003 Lux@F1.2 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR Distance |
Distance up to 40 m (131.23 ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR On/Off Control |
Auto/Manual |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR LEDs Number |
3 (IR LEDs) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pan/Tilt/Rotation Range |
Pan: 0°–355° Tilt: 0°–80° Rotation: 0°–355° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type |
Motorized vari-focal |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mount Type |
Module interface |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length |
2.7mm-12mm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Aperture |
F1.2 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Field of View |
Horizontal: 114°(W)–47°(T) Vertical: 59°(W)–27°(T) Diagonal: 141° (W–55°(T) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Iris Type |
Auto |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance |
w: 1 m (W: 3.28 ft) T: 2.5 m (T: 8.20 ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
||||||||||||||||||||||||||||||||||||||||||||||||||||||
W |
87.2 m (286.09 ft) |
34.9 m (144.50 ft) |
17.4 m (57.08 ft) |
8.7 m (28.54 ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
T |
186.7 m (612.53 ft) |
74.7 m (245.08 ft) |
37.3 m (122.37 ft) |
18.6 m (61.02 ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart event |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General IVS Analytics |
Abandoned object, moving object |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Professional, intelligent |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Protection |
Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); parking detection, loitering detection, and people gathering. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection |
Support face image capture |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Attributes |
Support 6 kinds of face attributes extraction: Age, Gender, Expression (Jolly, Surprise, Normal, Rage, Sad, Disgusted, Confused, Frightened), Glasses, Mouth Mask, Moustache & Beard |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
People Counting |
Count the entry number and exit number , display and output daily/monthly/annual report Count people in area, display and output daily/monthly/annual report |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression |
H.265, H.264, H.264H, H.264B, MJPEG |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Codec |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Frame Rate |
Main Stream: 3840 × 2160 (1–25/30 fps) Sub Stream 1: 704 × 576 (1–25/30 fps) Sub Stream 2: 1920 × 1080 (1–25/30 fps) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Stream Capability |
3 streams |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution |
8M (3840 × 2160)/6M (3072 × 2048/3072 × 1728)/5M (2592 × 1944)/4M (2688 × 1520)/3M (2048 × 1536/2304 × 1296)/1080p(1920 × 1080)/1.3M (1280 × 960)/720p(1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate Control |
CBR/VBR |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Bit Rate |
H.264: 32 Kbps–16384 Kbps H.265: 12 Kbps–16384 Kbps |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night |
ICR switch |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
BLC |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WDR |
120 dB |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gain Control |
Auto/Manual |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction |
3D DNR |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detection |
OFF/ON (4 areas, rectangular) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Region of Interest(RoI) |
Yes (4 areas) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Image Stabilization(EIS) |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart IR |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Defog |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 1080p resolution or below.) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mirror |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Privacy Masking |
4 areas |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression |
G.711a; G.711Mu; G726; AAC; G.723 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
RJ-45 (10/100 Base-T) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protocol |
HTTP; Https; 8021.x; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP; QoS; UPnP; NTP; SFTP; RTMP; Genetec;Bonjour |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; P2P |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scene Self-adaptation |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
User/Host |
20 (Total bandwidth: 160 M.) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Edge Storage |
FTP; Micro SD card (256 G); NAS; SFTP |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser |
IE: Versions later than IE9 Chrome: Versions later than Chrome 42, Firefox: Versions later than Firefox 48.0.2, |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Management Software |
Smart PSS; DSS; DMSS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mobile Phone |
IOS, Android |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications |
CE-LVD: EN60950-1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS-485 |
1 (Bit rate: 1200 bps-115200 bps) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input |
Audio Interface: 1/1 channel In/Out |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output |
Audio Interface: 1/1 channel In/Out |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Input |
3 channel In: 5mA 5V DC 2 channel Out: 1000mA 30V DC/500mA 50V AC |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output |
3 channel In: 5mA 5V DC 2 channel Out: 1000mA 30V DC/500mA 50V AC |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
12V DC/24V AC/PoE |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
<15.7W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environment |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature |
-40°C to +60°C (-40°F to +140°F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature |
≤95% |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature |
-40°C to +60°C (-40°F to +140°F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Ingress Protection |
IP67, IK10 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Structure |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing |
Metal + Plastic |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions |
129.1 mm × Φ157.9 mm (5.08″ × Φ6.22″) (L × W × H) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
1600 g (3.53 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
1500 g (3.31 lb) |
