Camera

Image Sensor

Two 1/2.8”3Megapixel progressive scan CMOS

Effective Pixels

2048(H)x1536(V)

RAM/ROM

512MB/4096MB

Scanning System

Progressive

Minimum Illumination

0.009Lux/F1.8 (Color,1/3s,30IRE)

0.08Lux/F1.8 (Color,1/30s,30IRE)

0Lux/F1.8(IR on)

S/N Ratio

More than 50dB

IR Distance

Distance up to 10m(33ft)

IR On/Off Control

Auto/ Manual

IR LEDs

1

Lens

Lens Type

Fixed

Mount Type

Board-in

Focal Length

2.8mm (3.6mm)

Max. Aperture

F1.8

Angle of View

H: 106° (80°), V:80° (58°)

Optical Zoom

N/A

Focus Control

Fixed

Close Focus Distance

0.6m (0.9m)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

45m(147ft)

18m(59ft)

9m(29ft)

4m(13ft)

3.6 mm

57m(187ft)

23m(75ft)

11m(36ft)

6m(19ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Tilt:-10˚~70˚;

Artificial Intelligence

People Counting

line crossing people counting, region people counting, Height filter, loitering filter

General Intelligence

Event Trigger

Motion detection, Video tampering, Scene changing,

Network disconnection, Ip address conflict, Illegal

access, Storage anomaly

General Intelligence

Heatmap

Video

Compression

H.265/H.264H/MJPEG(Sub Stream)

Smart Codec

Support H.265+/H.264+

Streaming Capability

3 Streams

Resolution

3MP(2048×1536)/ 1080P(1920×1080)/ 1.3M(1280×960)/ 720P(1280×720)/ D1(704×576/704×480) / VGA(640×480)/ CIF(352×288/342×240)

Frame Rate

Main Stream: 3MP (1~25fps)

Sub Stream 1: D1 (1 ~ 25/30fps)

Sub Stream 2: 6MP (1~7fps, For Debugging Only)
