> 1/1.8” 4Megapixel progressive scan CMOS
> H.265 & H.264 triple-stream encoding
> 25/30 fps@2688 × 1520, 50/60 fps@1080P (1920 × 1080)
> WDR (140 dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS
> 8 mm–32 mm motorized lens
> 2/1 Alarm in/out, 1/1 audio in/out
> Max. IR LEDs Length 120 m
> Micro SD memory, IP67, IK10
Camera |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor |
1/1.8” 4Megapixel progressive scan CMOS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Effective Pixels |
2688 (H) x 1520 (V) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM/ROM |
1 GB/128 MB |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System |
Progressive |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed |
Auto/Manual, 1/3 s–1/100000 s |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Minimum Illumination |
0.002 Lux@F1.6 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR Distance |
Distance up to 120 m (394 ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR On/Off Control |
Auto/ Manual |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR LEDs |
4 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type |
Motorized vari-focal |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mount Type |
Board-in |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length |
8 mm–32 mm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Aperture |
F1.6 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Angle of View |
H: 43°–15°, V:23°–8° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Aperture Type |
Auto (HALL) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance |
2.5 m–6.0 m (8.20 ft–19.69 ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
||||||||||||||||||||||||||||||||||||||||||||||||||||||
W |
151m(495ft) |
60.7m(199ft) |
30.3m(99ft) |
15.1m(49ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
T |
400m(1312ft) |
160m(525ft) |
80m(262ft) |
40m(131ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pan/Tilt/Rotation |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pan/Tilt/Rotation Range |
Pan:0˚–360˚; Tilt:0˚–90˚; Rotation:0˚–360˚ |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Artificial Intelligence |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Detection |
Support face image capture |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Attributes |
Support 6 kinds of face attributes extraction: Age, Gender,Expression (Jolly, Surprise, Normal, Rage, Sad, Disgusted, Confused, Frightened), Glasses, Mouth Mask, Moustache & Beard |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Perimeter Protection |
Tripwire, intrusion (Recognition of vehicle and people), fast moving, loitering detection, parking detection and people gathering |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
People Counting |
Support Line crossing/Region/Queueing people counting; Support 4 accesses independent detection, 4 areas independent detection |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Intelligence |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Event Trigger |
Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access,Storage anomaly |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Intelligence |
Object Abandoned/Missing |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Heat Map |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Compression |
H.265,H.264,H.264B,H.264H, MJPEG (sub stream) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Codec |
Yes |
