> H.265&H.264 double-stream encoding
> 25/30fps@1080P(1920×1080)
> Day/Night(Electronic), WDR, 3DNR, AWB, AGC, BLC
> Smart detection
> Micro SD memory, PoE
> Multiple Lens Unit optional
> Require a Lens Unit to work together
> Support connecting with 2 Lens Units
Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM/ROM | 512MB/32MB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
S/N Ratio | More than 50dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Intelligence | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IVS | Tripwire, Intrusion, Object Abandoned/Missing | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Advanced Intelligent Functions | Face Detection | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video (Working Together with Lens Unit) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Compression | H.265/H.264 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Streaming Capability | 2 Streams | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | 1080P(1920×1080)/ 1.3M(1280×960)/ 720P(1280×720)/ D1(704×576/704×480)/ VGA(640×480)/ CIF(352×288/342×240) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Frame Rate | Main Stream:
CH1: 1080P(1~25/30fps) CH2: 1080P(1~25/30fps) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Sub Stream:
CH1: CIF (1 ~ 25/30fps) CH2: CIF (1 ~ 25/30fps) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate Control | CBR/VBR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate | H.264: 24Kbps~ 9472Kbps
H.265: 14Kbps~ 5632Kbps |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night | Electronic | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
BLC Mode | BLC / HLC / WDR(120dB) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
White Balance | Auto/Natural/Street Lamp/Outdoor/Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gain Control | Auto/Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction | 3D DNR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detetion | Off / On (4 Zones, Rectangle) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Region of Interest | Off / On (4 Zones) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Image Stabilization (EIS) | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart IR | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Defog | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Digital Zoom | 16x | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Flip | 0°/90°/180°/270° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mirror | Off / On | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Privacy Masking | Off / On (4 Areas, Rectangle) |
