> 1/2.7” 4Megapixel progressive scan CMOS
> Day/Night(Electronic), WDR
> 2.8mm Fixed Pinhole Lens
> 8-meters cable
> Require a Main Box to work together
Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor | 1/2.7” 4Megapixel progressive scan CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System | Progressive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Effective Pixels | 2688(H)x1520(V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Minimum Illumination | 0.02Lux/F2.4 (Color,1/3s,30IRE)
0.08Lux/F2.4 (Color,1/30s,30IRE) 0.01Lux/F2.4 (B/W,1/3s,30IRE) 0.04Lux/F2.4 (B/W,1/30s,30IRE) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR Distance | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR On/Off Control | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR LEDs | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type | Fixed | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mount Type | Board-in | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length | 2.8mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Aperture | F2.4 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Angle of View | H:83.4° ,V:44.9° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Optical Zoom | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focus Control | Fixed | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance | N/A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance | Detect | Observe | Recognize | Identify | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
61m(200ft) | 24m(80ft) | 12m(40ft) | 6m(20ft) |
