System

Main Processor

Embedded Processor

Operating System

Embedded LINUX

Perimeter Protection

Performance

16 channel, 10 IVS rules for each channel

Object classification

Human/Vehicle secondary recognition for tripwire and intrusion

AI Search

Search by target classification (Human, Vehicle)

Face Recognition

Performance

Max 24 face pictures/sec processing (modeling and comparing)

Up to 6 channel video stream (analog channel max. supports 4 channel) human face recognition

Up to 16 channel picture stream human face recognition

Stranger Mode

Detect strangers’ faces (not in device’s face database).Similarity threshold can be set manually

AI Search

Up to 8 target face images search at same time, similarity threshold can be set for each target face image

Database Management

Up to 20 face databases with 100,000 face images in total. Name, gender, birthday, nationality, address, ID information can be added to each face picture

Database Application

Each database can be applied to video channels independently

Trigger Events

Buzzer, Voice Prompts, Email, Snapshot, Recording, Alarm Out, PTZ Activation, etc

Metadata

Face

Gender, age, glasses, beard, mask.

Human Body

top, top color, bottom, bottom color, hat, bag, gender, age, and umbrella

Motor Vehicle

Plate No., vehicle color, type, logo, plate color, ornament, calling, and seatbelt

Non-motor Vehicle

type, vehicle color, people number, and helmet

AI Search

Support search target video by metadata

Video and Audio

Analog Camera Input

16 Channel, BNC

HDCVI Camera

4K, 6MP, 5MP, 4MP, 1080P@25/30 fps, 720P@50/60 fps, 720P@25/30 fps

AHD Camera

5MP, 4MP, 3MP, 1080P@25/30 fps, 720P@25/30fps

TVI Camera

5MP, 4MP, 3MP, 1080P@25/30 fps, 720P@25/30fps

CVBS Camera

PAL/NTSC

IP Camera Input

64 Channel, each channel up to 12MP

Audio In/Out

4/1, RCA

Two-way Talk

Mic in & reuse Audio out for Mic out, RCA

Recording

Compression

H.265+, H.265, H.264+, H.264

Resolution

4K, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, 960H, D1, CIF

Record Rate

Main stream: 4K (1 fps–7 fps); 6MP (1 fps–10 fps); 5MP (1 fps–12 fps); 4MP/3MP (1 fps–15 fps); 4M-N/1080P/720P/960H/D1/CIF/QCIF (1 fps–25/30 fps)

Sub steram: 960H (1 fps–15 fps);

D1/CIF/QCIF (1 fps–25/30 fps)
